TSUNAMI STAINLESS STEEL INTELLIGENT HOME PUMP CMS iPT SERIES

RM1,224.00

SPECIFICATION
Model: CMS2-30-iPT
Power: 370w / 0.5Hp
Max. Head: 28m
Max. Flow: 3.5m³/h
Max. Speed: 2950rpm
Max. Liquid Temperature: 50°C
Frequency: 50Hz
Motor Phase: Single-Phase
Protection Class: IP55
Inlet / Outlet: 1″ X 1”

Model: CMS2-40-iPT
Power: 550w / 0.75Hp
Max. Head: 38m
Max. Flow: 3.5m³/h
Max. Speed: 2950rpm
Max. Liquid Temperature: 50°C
Frequency: 50Hz
Motor Phase: Single-Phase
Protection Class: IP55
Inlet / Outlet: 1″ X 1”

Model: CMS2-50-iPT
Power: 550w / 0.75Hp
Max. Head: 48m
Max. Flow: 3.5m³/h
Max. Speed: 2950rpm
Max. Liquid Temperature: 50°C
Frequency: 50Hz
Motor Phase: Single-Phase
Protection Class: IP55
Inlet / Outlet: 1″ X 1”

Model: CMS4-40-iPT
Power: 750w / 1.0Hp
Max. Head: 38m
Max. Flow: 3.5m³/h
Max. Speed: 2950rpm
Max. Liquid Temperature: 50°C
Frequency: 50Hz
Motor Phase: Single-Phase
Protection Class: IP55
Inlet / Outlet: 1¼″ X 1”

Weight (Unit): 17kg
Dimension(W x L x H): 390 x 420 x 690 mm

Scope Of Delivery
• 1x Tsunami Stainless Steel Intelligent Home Booster Pump CMS iPT Series

WARRANTY PERIOD : RESIDENTIAL : 24 MONTHS / COMMERCIAL : 12 MONTHS

Description

The Tsunami CMF iPT Series is a line of high-performance, multistage stainless steel booster pumps designed to deliver consistent and reliable water pressure in residential and light commercial applications. Constructed with high-strength stainless steel, these pumps ensure durability and longevity, making them suitable for various water supply and pressure-boosting needs.

• Stainless Steel Construction: Pump body, inlet, outlet, shaft, and impeller are made of stainless steel for corrosion resistance and durability.
• Multistage Design: Provides high efficiency and stable pressure output.
• Dry-Running Protection: Prevents motor damage due to lack of water.
• Digital Indicator: Displays operational status and settings.
• Adjustable Pressure Settings: Allows customization of cut-in and cut-off pressure points.
• Maintenance-Free Operation: Designed for long-term, hassle-free use.
• Reduced Water Hammering: Minimizes pressure surges in the piping system.
• Restart System: Automatically restarts after dry-run conditions are resolved.

Application:
• Residential Water Pressure Boosting: Enhances water pressure for showers, taps, and appliances in homes.
• Small Commercial Establishments: Suitable for cafes, laundromats, and other businesses requiring consistent water pressure.
• Water Supply Systems: Ideal for supplying water in multi-storey buildings.
• Irrigation Systems: Provides steady water flow for gardens and small agricultural setups.
• Water Treatment Processes: Assists in various stages of water purification and distribution.

Additional information

Weight 20 kg
Dimensions 39 × 42 × 69 cm
