TSUNAMI CENTRIFUGAL STAINLESS STEEL PUMP TWK SERIES
RM690.00
SPECIFICATION
Model : TCK-50T
Power : 0.55kW / 0.74Hp
Voltage: 415v
Frequency: 50Hz
Max.Flow: 12m³/h
Max. Head: 7m
Motor Phase: Three-Phase
Inlet / Outlet: 1¼ x 1
Model : TCK-120T
Power : 0.15kW / 1.0Hp
Voltage: 415v
Frequency: 50Hz
Max.Flow: 12m³/h
Max. Head: 10m
Motor Phase: Three-Phase
Inlet / Outlet: 1½ x 1½
Model : TCK-150T
Power : 1.1kW / 1.47Hp
Voltage: 415v
Frequency: 50Hz
Max.Flow: 18m³/h
Max. Head: 10m
Motor Phase: Three-Phase
Inlet / Outlet: 2 x 2
Model : TCK-200T
Power : 1.50kW / 2.0Hp
Voltage: 415v
Frequency: 50Hz
Max.Flow: 18m³/h
Max. Head: 10.5m
Motor Phase: Three-Phase
Inlet / Outlet: 2 x 2
Model : TCK-300T
Power : 2.2kW / 2.95Hp
Voltage: 415v
Frequency: 50Hz
Max.Flow: 30m³/h
Max. Head: 11m
Motor Phase: Three-Phase
Inlet / Outlet: 2½ x 2
Model : TCK-400T
Power : 3.0kW / 4.0Hp
Voltage: 415v
Frequency: 50Hz
Max.Flow: 30m³/h
Max. Head: 15m
Motor Phase: Three-Phase
Inlet / Outlet: 2½ x 2
Dimension (W x L x H): 250 x 490 x 330 mm
Weight: 24 kg
Scope Of Delivery
• 1x Tsunami Centrifugal Stainless Steel Pump TWK Series
WARRANTY PERIOD : RESIDENTIAL : 24 MONTHS / COMMERCIAL : 12 MONTHS
Description
The Tsunami TWA Series is a line of self-priming, centrifugal water pumps specifically designed for clean and slightly muddy water transfer. Engineered for durability and convenience, the TWA Series is ideal for a wide range of applications requiring efficient water movement, especially where suction lift is needed.
• Self-priming design for easy startup without foot valve
• Rugged cast iron body for long service life
• High efficiency impeller for strong suction and discharge performance
• Compact, space-saving construction
• Low maintenance and user-friendly design
• Thermal overload protection on selected models
Application:
• General water supply and drainage
• Irrigation for farms, gardens, and nurseries
• Water transfer from wells, tanks, and reservoirs
• Light construction site dewatering
• Livestock watering and small-scale agricultural systems
Additional information
| Weight | 30 kg |
|---|---|
| Dimensions | 35 × 49 × 33 cm |
