POTENZA STAINLES STEEL JET PUMP PSM-3-40/045-PC
RM950.00
SPECIFICATION
Model: PSM-3-40/045-PC
Power Supply : 240 V AC (Single Phase)
Motor Power : 0.6 HP / 0.45 kW
Max Flow Rate : 70 L/min
Max Head : 30 meters
Max Working Pressure : 6 bar
Pump Type : Stainless Steel Jet Pump
Motor Type : 2-Pole Induction Motor (TEFC)
Duty Type : Continuous Duty
Thermal Protection : Yes (Automatic)
Protection Class : IP44
Insulation Class : Class F
Operating Temperature : -15°C to +40°C
Liquid Temperature : Up to 80°C
Control : Integrated Automatic Pressure Controller
Noise Level : Low Noise Operation
Dimensions: 250 x 450 x 300 mm
Weight: 11 kg
Performance
• Max Flow Rate: 100 L/min
• Max Head: 33 meters
• Recommended Operating Range: 30–80 L/min
• Ideal for maintaining steady pressure in 3–4 bathroom homes or light business use
• Quiet & Efficient, even at high performance levels
Scope Of Delivery
• 1x Potenza Stainless Steel Jet Pump PSM-3-40/045-PC
12 MONTHS WARRANTY
Description
The Potenza PSM-3-40/045-PC is a powerful yet compact stainless steel jet pump with a built-in pressure controller. Designed for efficient water boosting in small homes and light commercial spaces, it delivers strong flow, quiet operation, and reliable performance. With energy-saving features and automatic protection, it ensures consistent water pressure and peace of mind every day.
• Integrated Pressure Controller
– Automatically maintains consistent water pressure without the need for a separate control unit.
• Compact & Silent Operation
– Designed for quiet performance, making it perfect for home or office use.
• Energy Efficient Motor
– Built with a 0.45 kW high-efficiency motor to save on electricity bills while delivering strong performance.
• Corrosion-Resistant Build
– SUS304 stainless steel construction ensures long-term durability and resistance to rust.
• Thermal Overload Protection
– Comes with built-in safety to prevent motor overheating and extend lifespan.
• Easy Installation & Maintenance
– Lightweight, user-friendly design allows for fast setup and minimal maintenance.
• Reliable for Daily Use
– Perfect for small households, water filtration systems, or light-duty commercial needs.
• Small Commercial Spaces
• Water Filtration Systems
• HVAC Systems
• Washing & Cleaning Systems
Material Construction
• Pump Body & Casing : SUS304 Stainless Steel
• Impeller & Shaft : SUS304 Stainless Steel
• Mechanical Seal : NBR / Carbon / Ceramic
• Optional Seal Upgrade: Viton (for high-temp applications)
• Back Cover & Guide Plate: SUS304 Stainless Steel
• Motor Casing & Bracket: High-Grade Aluminum
• Bearings: NSK (Made in Japan)
Additional information
| Weight | 12 kg |
|---|---|
| Dimensions | 25 × 45 × 30 cm |
